Specification
- Controls: Gain, Tone, Level
- Switches: True Bypass footswitch, Hi/Lo Mode toggle switch
- LED Indicators: Red, yellow, and blue bugles in the Maestro logo illuminate when the pedal is active
- Signal Processing: All-Analog
- Power Requirements: 9V battery or regulated 9-12*VDC power supply (5.5 x 2.1mm plug, wired center-negative) *Running the pedal at 12V provides increased headroom
- Current Draw: 30.4 mA
- Power On Switch: Incorporated into the input jack. Unplug the input when not in use to prevent battery drain. Remove the battery when the pedal is going to be stored for long periods to prevent leakage and damage.
- Input Impedance: 1M ohms
- Output Impedance: 1K ohms
- Switching: True Bypass
- Dimensions (D x W x H): 5.04” x 3.45” x 2.5”, including feet, knobs, jacks, etc.
- Weight (Including Battery): 1.1 lb. / 498.95 gm.
